GranITe-Room.cert

GranITe-Room.cert
Certified IT-Data Centers for Highest Security
Modular – Certified – Highly Available

GranITe stands for security & resistance! The GranITe-Room.cert offers an extremely high degree of protection for IT infrastructures. Special characteristics of this IT room system make it into a truly high security wing for your IT.

The room offers proven protection against all physical dangers such as fire, break-ins, vandalism, water or even flying debris. Utilities (ventilation, electrical & energy-related technology) are ideally integrated into the security concept.

And additionally, a large number of unique technological features provide just as many advantages in IT operation. From a constructional perspective, the GranITe-Room.cert plays a pioneering in the field of room efficiency with its modular system and full use of available standing space (practically next to the walls). Whether in the basement or top floor, all available space will be put to use and that means from 5 up to 5,000 sqm.

Product Details:

Modular system of construction(wall, ceiling and floor elements)
Steel elements, filled with highly efficient insulation
High security door system with 6-point interlock, monitoring contacts, mechanical key-lock and sliding door closer
Round cable duct DN200
High carrying capacity through load-carrying ceiling
Independent of location
(Re)movable during running operation
Low static floor loads

Test Certificates:

ECB•S certification acc. to EN 1047-2
Impact test acc. to EN 1047-2
EI180 Building component test (external) acc. to EN 1363-1 and EN 13501-2
EI120 Building component test (internal) acc. to EN 1363-1 and EN 13501-2
Burglar protection RC 2 acc. to EN 1630
Resistance to flying debris
Dust protection IP 56 acc. to EN 60529
Extinguishing-water protection IP 56 acc. to EN 60529
Protection against standing-water
Smoke tightness acc. to EN 1634-3
Noise protection acc. to DIN 4109, DIN EN ISO 354, DIN EN ISO 140, DIN EN ISO 717
Explosion protection
Escape door certification acc. to EN 179 (optional EN 1125)
EMC protection acc. to EN 50147
